29R Series 2 Snowplow
8’10” Blade
The Ultimate Snow Moving Machine!
The 29R snowplow stands out from the crowd with the greatest possible snow moving flexibility and capacity for your plow truck. No more machine limitations!
Also available for Skid Steer and Tractors
Product Description
The 29R Series 2 snowplow is 8’10” wide and 29 inches tall plow and moves more snow than any plow in this class.
The “R” in the model identifier refers to the Revolution™ series of snowplows. These plows are designed with patented hydraulic end wings that that can be controlled together or independently to move the snow where you want it at any time. Each wing can be moved from a straight out position into a 90 degree orientation to the main blade – effectively creating a box plow. This patented dual-wing plow design provides you the ability to move up to 4.8 cubic yards of snow which is double the closest competitor’s V plow or expandable plow!
Engage the Patented Down Pressure® Hydraulics System that increases snow clearing capacity another 30% and you have the ultimate snow clearing machine.
Common Truck Applications: 3/4 Ton: F-250, Ram 2500, 2500 Sierra, 2500 Silverado 1 Ton: F-350, Ram 3500, 3500 Sierra, 3500 Silverado
Specs
Model
29R
Blade Width
106"
30° angle plow width
92"
Blade Height
29"
Width in Feet
8'10"
Weight
705 lbs.
Cutting Edge
3/8" x 6"
Vertical/Diagonal Ribs
5
Trip Springs: Extension
2
Plow Shoes
optional
Shock Killer™ System
Standard
Paint (Triple Coat Protection)
Standard
Plow Lights
ESS®LED Thermosensitive
Down Pressure® Hydraulic System
Standard
FlexForce Frame
Standard
Wireless Control
Optional
Mount System
Drive In
Product Highlights
ESS® Smart System
Downtime reduction Eliminates all failure-prone relays Corrosion elimination Military grade connectors keep moisture out (in…
Ground Hugger™
Sno-Way’s® Ground Hugger™ blade design transfers pressure from the snow loads to the blade –…
Double Hinge Plows
No-gap wing design The patented Double Wing Mechanism offered in the Revolution Series of plows…
Pre-Drilled Top Blade Rail
The pre-drilled top blade rail allows for E-Z installation of So-Way’s E-Z Fit Deflector.
Down Pressure® Hydraulics System
Eliminates the skim layer that all other plows leave Sno-Way’s® patented Down Pressure® snow plow…
Drive-in Mount
Easy-to-use, super fast mounting system Early Sno-Way® plow designs used an easy-on, easy-off plow mount…
Triple-Coat Protection
We start with zinc phosphate wash as an initial layer to prevent corrossion. Then…
Tube Steel/Tab-Slot and Lock Construction
Tab-Slot and Lock construction makes the structural components link fully together. After welding tab-slot and…
90° Hydraulic Wing Rotation
90° hydraulic wing rotation provides infinite snow moving adjustability! Patented hydraulic end wings that can…
Product Documents
| Document | Title | Content | Manual Types | Link | hf:tax:document-manual-type |
|---|---|---|---|---|---|
| 97101634C | SNO-WAY E-Z FIT WELDED-IN SKIN STRAIGHT BLADE SNOW DEFLECTOR (P/N 99101042) | FOR 26 26R 29R 29HD 29THD 32 CONTRACTOR REV HD MBR & MBC SERIES PLOWS | Owners/Install | owners-install | |
| 97101716C | SNO-WAY E-Z FIT SKIN INSERT | FOR MBC MBR 29HD 29R & 26 SERIES PLOWS | Owners/Install | owners-install | |
| 97101705A | MECHANICAL PARTS & ACCESSORIES - 29HD & 29R SERIES SNOW PLOWS | MECHANICAL PARTS & ACCESSORIES – 29HD & 29R SERIES SNOW PLOWS | Poster/Counter Mat Insert | poster-counter-mat-insert | |
| 97101917D | TROUBLESHOOTING GUIDE PROCONTROL™ AND PROCONTROL™ II, AND PROCONTROL™ 2 PLUS | STRAIGHT BLADE 29VHD & “R” SERIES AND UTV SNOW PLOWS | Troubleshooting Guides | troubleshooting-guides |
